SURPASS HOBBY 2822 2826 2830 2836 3530 3536 3542 3548 5065 Drone Brushless Motor for RC FPV 3D Fixed Wing Quadcopter Multicopter
Description:
It is built from high quality aluminum alloy which is produced from the latest CNC milling machines, and is designed with high power and rotation speed to provide longer run time for RC airplane fixed-wing.
It is built from high quality aluminum alloy which is produced from the latest CNC milling machines, and is designed with high power and rotation speed to provide longer run time for RC airplane fixed-wing.
Features:
14 Pole 12 slot hi-torque motor design
CNC machined 6061 T6 billet aluminum heatsink can
High purity copper windings maximizes efficiency
High RPM ABEC5 oversized bearings
Precision balanced rotor, smoothness for best reliability and maximum RPM
Stator-super thin (0.2mm) laminations
Precision engineered for maximum energy conversion
Specification:
Brand name: SURPASS HOBBY
Item No.: C2822
KV(RPM/Volt): 1200KV/1400KV Optional
KV(RPM/Volt): 1200KV/1400KV Optional
Watt: 140W/160W
Voltage range: 7-15V
Max amps: 11A/13A
Resistance: 0.368/0.307
Motor size: Ø28 * 20mm
Staror size: 2204
Recommended propeller: 8*5 / 8*6 / 7*5 7.5 * 3.5 / 8 * 4 / 9 * 5
Recommended propeller: 8*5 / 8*6 / 7*5 7.5 * 3.5 / 8 * 4 / 9 * 5
Connector: 3.5mm golden banana connector
Weight: 30g
Item No.: C2826
KV(RPM/Volt): 1000KV/1350KV/1900KV Optional
Watt: 220W/240W/250W
Voltage range: 7-12V
Max amps: 20A/24A/27A
Resistance: 0.256/0.097/0.063
Motor size: Ø28 * 24mm
Staror size: 2208
Recommended propeller: 8*5 / 8*7 / 9*4.7 8 * 3.8 / 7*4 8*3.8 / 8*4 / 7*5
Connector: 3.5mm golden banana connector
Weight: 45g
Suitable for: 100-350g airplane
Item No.: C2830
KV(RPM/Volt): 750KV/850KV/1000KV/1300KV Optional
Watt: 230W/240W/260W/300W
Voltage range:7-15V/7-15V/7-15V/7-12V
Max amps: 18A/19A/21A/25A
Resistance: 0.221/0.189/0.152/0.085
Motor size: Ø28 * 28mm
Staror size: 2212
Recommended propeller: 11x5.5/10x7 11x5.5/9x6/10x4 9x4.5/10x6/10x5 9x6/10x5/10x6
Connector: 3.5mm golden banana connector
Weight: 45g
Suitable for: 300-700g airplane
Item No.: C2836
KV(RPM/Volt): 750KV/880KV/1120KV Optional
Voltage range: 7-12V
Max current: 28A
Rotor poles: 14
No load Current: 1.4A
Resistance: 0.035
Motor Size: ￠28 * 36mm
Stator size: 2216
Recommended propeller: 9*6/10*5/10*6
Connector: 3.5mm golden banana connector
Weight: 53.3g
Item No.: C2826
KV(RPM/Volt): 1000KV/1350KV/1900KV Optional
Watt: 220W/240W/250W
Voltage range: 7-12V
Max amps: 20A/24A/27A
Resistance: 0.256/0.097/0.063
Motor size: Ø28 * 24mm
Staror size: 2208
Recommended propeller: 8*5 / 8*7 / 9*4.7 8 * 3.8 / 7*4 8*3.8 / 8*4 / 7*5
Connector: 3.5mm golden banana connector
Weight: 45g
Suitable for: 100-350g airplane
Item No.: C2830
KV(RPM/Volt): 750KV/850KV/1000KV/1300KV Optional
Watt: 230W/240W/260W/300W
Voltage range:7-15V/7-15V/7-15V/7-12V
Max amps: 18A/19A/21A/25A
Resistance: 0.221/0.189/0.152/0.085
Motor size: Ø28 * 28mm
Staror size: 2212
Recommended propeller: 11x5.5/10x7 11x5.5/9x6/10x4 9x4.5/10x6/10x5 9x6/10x5/10x6
Connector: 3.5mm golden banana connector
Weight: 45g
Suitable for: 300-700g airplane
Item No.: C2836
KV(RPM/Volt): 750KV/880KV/1120KV Optional
Voltage range: 7-12V
Max current: 28A
Rotor poles: 14
No load Current: 1.4A
Resistance: 0.035
Motor Size: ￠28 * 36mm
Stator size: 2216
Recommended propeller: 9*6/10*5/10*6
Connector: 3.5mm golden banana connector
Weight: 53.3g
Suitable for: 300-700g airplane
Item No.: C3530
KV(RPM/Volt): 1100KV/1400KV/1700KV Optional
Voltage range: 7-15V
Max current: 30A/35A/42A
Rotor poles: 14
No load Current: 0.7A/1.2A/1.8A
Resistance: 0.113/0.059/0.041
Motor Size: ￠35 * 29mm
Stator size: 2808
Recommended propeller:9x5/10x4.79x4.5/8x4/7x7 7x4/6x6
Connector: 3.5mm golden banana connector
Weight: 78g
Item No.: C3536
KV(RPM/Volt): 910KV/1050KV/1300KV/1500KV Optional
Watt:400W/500W/680W/750W
Voltage range:7-15V
Max amps: 30A/38A/50A/55A
Resistance: 0.072/0.055/0.038/0.025
Motor size: Ø35 * 35mm
Staror size: 2814
Recommended propeller:10x7/11x8.5/12x5 9.5x5/10x6/11x5 9x4.5/10x4.7/9x5 8x4/9x6/10x6
Connector: 3.5mm golden banana connector
Weight: 159.2g
Suitable for: 1-1.5kg airplane
Item No.: C3542
KV(RPM/Volt): 1000KV/1250KV/1450KV Optional
Watt:750W/850W/1050W
Voltage range:7-15V
Max amps: 55A/65A/78A
Resistance: 0.039/0.026/0.021
Motor size: Ø35 * 41mm
Staror size: 2820
Recommended propeller:10x6/12x6.5/13x8 8x7/9x5/10x4 12x5/11x7/13x8
Weight: 194.2g
Item No.: C3548
KV(RPM/Volt): 790KV/900KV/1100KV Optional
Watt:840W/1000W/1100W
Voltage range:10-20V/7-18V/7-15V
Max amps: 50A/60A/72A
Resistance: 0.051/0.033/0.028
Motor size: Ø35 * 47mm
Staror size: 2826
Recommended propeller:12x7/13x7/14x7 11x8/13x6/14x7 12x6/12x6.5/13x8
Weight: 220.2g
Item No.: C4260
KV(RPM/Volt): 600KV
Watt:1500W
Voltage range:10-20V
Max amps: 75A
Resistance: 0.0291
Motor size: Ø42 * 60mm
Staror size: 3530
Recommended propeller:15x8/16x8/16x10
Weight: 275g
Item No.: C5045
KV(RPM/Volt): 720KV/890KV Optional
Watt:860W
Voltage range:10-20V/10-18V
Max amps: 43A/48A
Resistance: 0.0275/0.0215
Motor size: Ø50 * 44mm
Staror size: 4110
Recommended propeller:14x7/12x10/13x8 12x6/13x10/13x8
Weight: 195g
Item No.: C5055
KV(RPM/Volt): 400KV/570KV/760KV Optional
Watt:1660W
Voltage range:10-20V
Max amps: 83A
Resistance: 0.0173
Motor size: Ø50 * 54mm
Staror size: 4120
Recommended propeller:14x8/15x8/17x9
Weight: 408.2g
Item No.: C5056
KV(RPM/Volt):335KV
Watt:1600W
Voltage range:15-30V
Max amps: 53A
Resistance: 0.0421
Motor size: Ø50 * 64mm
Staror size: 4130
Recommended propeller:16x10/18x10/18.5x12
Weight: 375g
KV(RPM/Volt): 1100KV/1400KV/1700KV Optional
Voltage range: 7-15V
Max current: 30A/35A/42A
Rotor poles: 14
No load Current: 0.7A/1.2A/1.8A
Resistance: 0.113/0.059/0.041
Motor Size: ￠35 * 29mm
Stator size: 2808
Recommended propeller:9x5/10x4.79x4.5/8x4/7x7 7x4/6x6
Connector: 3.5mm golden banana connector
Weight: 78g
Item No.: C3536
KV(RPM/Volt): 910KV/1050KV/1300KV/1500KV Optional
Watt:400W/500W/680W/750W
Voltage range:7-15V
Max amps: 30A/38A/50A/55A
Resistance: 0.072/0.055/0.038/0.025
Motor size: Ø35 * 35mm
Staror size: 2814
Recommended propeller:10x7/11x8.5/12x5 9.5x5/10x6/11x5 9x4.5/10x4.7/9x5 8x4/9x6/10x6
Connector: 3.5mm golden banana connector
Weight: 159.2g
Suitable for: 1-1.5kg airplane
Item No.: C3542
KV(RPM/Volt): 1000KV/1250KV/1450KV Optional
Watt:750W/850W/1050W
Voltage range:7-15V
Max amps: 55A/65A/78A
Resistance: 0.039/0.026/0.021
Motor size: Ø35 * 41mm
Staror size: 2820
Recommended propeller:10x6/12x6.5/13x8 8x7/9x5/10x4 12x5/11x7/13x8
Weight: 194.2g
Item No.: C3548
KV(RPM/Volt): 790KV/900KV/1100KV Optional
Watt:840W/1000W/1100W
Voltage range:10-20V/7-18V/7-15V
Max amps: 50A/60A/72A
Resistance: 0.051/0.033/0.028
Motor size: Ø35 * 47mm
Staror size: 2826
Recommended propeller:12x7/13x7/14x7 11x8/13x6/14x7 12x6/12x6.5/13x8
Weight: 220.2g
Item No.: C4260
KV(RPM/Volt): 600KV
Watt:1500W
Voltage range:10-20V
Max amps: 75A
Resistance: 0.0291
Motor size: Ø42 * 60mm
Staror size: 3530
Recommended propeller:15x8/16x8/16x10
Weight: 275g
Item No.: C5045
KV(RPM/Volt): 720KV/890KV Optional
Watt:860W
Voltage range:10-20V/10-18V
Max amps: 43A/48A
Resistance: 0.0275/0.0215
Motor size: Ø50 * 44mm
Staror size: 4110
Recommended propeller:14x7/12x10/13x8 12x6/13x10/13x8
Weight: 195g
Item No.: C5055
KV(RPM/Volt): 400KV/570KV/760KV Optional
Watt:1660W
Voltage range:10-20V
Max amps: 83A
Resistance: 0.0173
Motor size: Ø50 * 54mm
Staror size: 4120
Recommended propeller:14x8/15x8/17x9
Weight: 408.2g
Item No.: C5056
KV(RPM/Volt):335KV
Watt:1600W
Voltage range:15-30V
Max amps: 53A
Resistance: 0.0421
Motor size: Ø50 * 64mm
Staror size: 4130
Recommended propeller:16x10/18x10/18.5x12
Weight: 375g
Package list:
1 * SURPASS HOBBY C2822 C2826 C2830 C2836 C3530 C3536 C3542 C3548 C4260 C5045 C5055 C5065 Motor
1 * Mounting Parts Set
Note:Only the above package content, other products are not included.
1.Due to the difference between different monitors,the picture may not reflect the actual color of the item. We guarantee the style is the same as shown in the pictures.
2.Due to the manual measurement and different measurement methods, please allow 1-3mm deviation.make sure you do not mind before you bid.Thanks!
1.Due to the difference between different monitors,the picture may not reflect the actual color of the item. We guarantee the style is the same as shown in the pictures.
2.Due to the manual measurement and different measurement methods, please allow 1-3mm deviation.make sure you do not mind before you bid.Thanks!
